Forearm injuries and fractures

Injury to the forearm usually results from trauma secondary to, for example, a fall, a road traffic accident or a sporting injury. It can also result from overuse. Injuries include muscle strain and contusion, crush injuries, fractures and tendon and nerve injuries.

Anatomy of the forearm

The radius and ulna have an important role in positioning the hand. The ulna has a stabilising role, while the radius is articulated in a way which allows it to roll over the ulna, moving the hand from supination (external rotation) to pronation (internal rotation).

• The two bones of the forearm are the radius, laterally, and the ulna, medially. Other components of the forearm include skin, blood vessels, and soft tissue.

• At its upper end, the radius articulates with the capitulum of the humerus at the elbow, and with the ulna (superior radioulnar joint). At its lower end it articulates with the scaphoid and lunate bones and also with the ulna (inferior radioulnar joint).

• At its upper end, the ulna articulates with the trochlea of the humerus, and with the head of the radius (superior radioulnar joint). At its lower end it articulates with the radius (inferior radioulnar joint).

• The olecranon process at the upper end of the ulna forms the prominence of the elbow. The styloid processes of the radius and the ulna form prominences at the wrist.

Forearm fractures

Forearm fractures account for most limb fractures. Wrist fractures are the most common forearm fracture¹ . Fracture risk factors include osteoporosis (more common in women than in men) and malignancy (pathological fractures). Fractures of the radius and ulna may occur in isolation - usually due to a direct blow - but these are usually associated with fracture or displacement of the other bone in that forearm² . An epidemiological study in Denmark found that 4 out of 5 forearm fractures were treated conservatively³ .

Classification

• Forearm fractures can be classified as either proximal, middle or distal.

• They can affect one or both forearm bones.

• They are either open or closed.

• Proximal forearm fractures may involve the elbow joint (see the separate Elbow Injuries and Fractures article; see the section below for Monteggia fractures).

• Distal forearm fractures may involve the wrist (see the separate Wrist Fractures article).

General assessment and initial management of forearm fractures

Some general principles should be followed for all forearm fractures. Specific points related to the different fracture types are discussed below. Forearm fractures in children can generally be treated differently from adult fractures because of continuing bone growth in the radius and the ulna after the fracture has healed⁴ .

• Assess Airway, Breathing and Circulation and manage as necessary.

• Assess upper limb neurovascular function:


  • Sensory function: the median nerve supplies the thumb, index, middle and radial half of the ring finger on the palmar side of the hand and the tip of the thumb, index, middle and ring finger on the dorsum of the hand; the radial nerve supplies the dorsolateral aspect of the hand and the dorsal aspect of the thumb, index, middle and lateral half of the ring fingers; the ulnar nerve supplies the dorsal and palmar aspects of the medial half of the ring finger and the whole of the little finger.

  • Motor function: test the anterior interosseous branch of the median nerve by asking the patient to make the 'OK' sign (touching the tips of the first and second fingers with the thumb); test the radial nerve by asking the patient to extend their fingers or wrist against resistance; test the ulnar nerve by asking the patient to separate their fingers against resistance.

  • Vascular function: examine the radial (and ulnar) pulse. Assess capillary refill.

• Examine the wrist, elbow and forearm for tenderness and range of motion.

• Perform a complete examination for other injuries.

• Immobilise the forearm and upper arm whilst waiting for X-ray.

• Provide analgesia.

• Immediate fracture reduction is required if there is neurovascular compromise, severe displacement or skin tenting.

Adult both-bone forearm fractures

• Mechanism of injury: usually a significant force injury. These most commonly occur in motor vehicle accidents, and also occur from a direct blow, a fall from a height or during sport.

• Presentation: pain and swelling at the site with obvious deformity.

• Assessment: may be nerve involvement with paraesthesiae, paresis or loss of function. Do not elicit crepitus, as this may cause further soft tissue injury. Do not probe open fractures as this may cause deeper contamination.

• Investigation: X-ray the entire length of the forearm, wrist and elbow, with AP and lateral views. Consider compartment syndrome.

• Management: displaced fractures are the usual situation in adults. Operative treatment with internal fixation or intramedullary nailing will be needed in nearly all cases, so refer urgently. Closed reduction may be attempted (with sufficient sedation/analgesia ± muscle relaxants) if there is acute neurovascular compromise. Notable complications of surgery include non-union, malunion, and re-fracture after the removal of the fixation device⁵ .

Paediatric both-bone forearm fractures

Fractures may be of greenstick type (incomplete) or complete. A greenstick fracture can occur in one bone with a complete fracture in the other. Complete fractures may be undisplaced, minimally displaced or overriding. Fractures of the proximal third are relatively rare. Middle third fractures account for about 18% of both-bone fractures and distal third fractures for about 75%⁶ .

• Mechanism of injury: usually an indirect injury following a fall on to an outstretched hand. Occasionally caused by a direct trauma.

• Presentation: pain, swelling and deformity at the fracture site.

• Investigation: X-rays of the wrist, elbow and whole forearm should be taken.

• Management: unlike the management of these fractures in adults, conservative management is still the first line of treatment for paediatric forearm fractures, especially in children less than 10 years old. Due to a child’s physeal growth potential, varying degrees of fracture angulation can be accepted - depending on the age of the child and his or her ability to remodel⁷ . After reduction, forearm pronation and supination should be checked and the arm placed in a long-arm cast or splint. Surgical treatment is by open reduction and plating/intramedullary nails, depending on the degree of overriding/angulation⁶ .

Radial shaft fractures (Galeazzi fractures)

• Definition: solitary fractures of the distal one third of the radius with accompanying subluxation or dislocation of the distal radioulnar joint (DRUJ). The synonym is reverse Monteggia's fracture⁸ .

• Mechanism of injury: commonly caused by a fall on to an extended, pronated wrist.

• Presentation: pain, swelling and deformity of the wrist and forearm. Tenderness and swelling at the distal radius and tenderness at the DRUJ.

• Investigation: X-ray the entire length of the forearm including wrist and elbow joints; AP and lateral views are usually sufficient.

• Management: in adults, this requires surgical open reduction of the distal radius and DRUJ with internal fixation. In children, the fracture can often be treated by closed reduction with longitudinal traction and correction of radial angulation. General anaesthesia (GA) may be required in difficult cases. If closed reduction under GA fails, K-wire insertion may be needed to lever the fracture into position. Open reduction may be needed in some cases⁸ .

Ulnar shaft fractures

• Definition: isolated mid-shaft ulnar fractures have the synonym 'nightstick fracture'.

• Mechanism of injury: usually caused by a direct blow to the ulnar border, classically if someone receives a blow from an object whilst raising their arm in defence⁹ .

• Presentation: point tenderness over the ulnar shaft, and forearm swelling.

• Investigation: need to X-ray the ulna from the wrist to the elbow.

• Management: this requires orthopaedic referral. Non-displaced or minimally displaced fractures can be treated with a posterior splint from the mid-upper arm to the dorsum of the metacarpal joints with the wrist in slight extension, the forearm in a neutral position and the elbow at 90°. After 7-10 days, when swelling has subsided, use a plaster sleeve or functional brace for the following 4-6 weeks. Monitor weekly for the first three weeks for any displacement. Fractures with marked displacement or angulation should be treated with open reduction and internal fixation.

Monteggia's fractures

• Definition: these are fractures of the proximal third (usually) of the ulna with associated dislocation of the radial head. Classified as:


  • Type I - fracture with anterior radial head dislocation. This is the most common (60%)¹⁰ .

  • Type II - fracture of the proximal ulna with posterior or posterolateral dislocation of the radial head (15%)¹⁰ .

  • Type III - fracture of the ulnar metaphysis with lateral or anterolateral dislocation of the radial head (20%)¹⁰ .

  • Type IV - fracture of both the radius and ulna at their proximal third with anterior dislocation of the radial head (5%)¹⁰ .

• Mechanism of injury: usually caused by a fall on to an outstretched, extended and pronated elbow, or by a direct blow.

• Presentation: acute, severe pain and swelling in the forearm and elbow. Damage may occur to the posterior interosseous nerve.


  Monteggia fracture




  By Jane Agnes (own work), via Wikimedia Commons



• Investigation: X-ray the entire length of the radius and ulna, including the wrist and elbow - AP and lateral views are usually sufficient but there may be a need for radiocapitellar views.

• Management: in adults, immobilise the joint in a splint and refer for open reduction and internal fixation. Most paediatric Monteggia's fractures are treated closed¹¹ .

Complications of forearm fractures

See the general separate Complications from Fractures article.

• Non-union and malunion (uncommon).

• Compromise of the brachial/radial artery blood supply.

• Median, ulnar or radial nerve injury.

• Infection (more likely if the fracture is secondary to a crush injury).

• Compartment syndrome (more common in both-bone forearm fractures).

• Radioulnar fusion (synostosis).

• Re-fracture.

Prevention of forearm fractures

• Prevention of osteoporosis.

• Adequate treatment of existing osteoporosis.

• The use of wrist and elbow guards whilst taking part in certain sporting activities, such as mountain biking and skating.

Forearm overuse injuries

• Apart from tennis and golfer's elbow (lateral and medial epicondylitis), forearm overuse injuries are not that common outside the realms of sports medicine.

• Commonly, they affect athletes who take part in racquet or throwing sports. If an activity involves repetitive flexion-extension of the elbow or pronation-supination of the wrist, it can lead to an overuse injury.

• Ulnar nerve injury and olecranon stress fractures can also occur if there is increased stress on the elbow joint.

• Three major nerves cross the elbow joint: the median nerve, the ulnar nerve and the radial nerve. Overuse injuries or direct trauma to the elbow can affect these nerves.

• Pronator syndrome and radial tunnel syndrome can occur in sports where there is excessive wrist flexion-extension or pronation-supination.

• History taking is an essential part of the examination.

Pronator syndrome

• This is due to entrapment of the median nerve.

• There is pain or paraesthesia over the median nerve distribution in the anterior proximal forearm. It is aggravated by throwing/swinging a racquet.

• It can be distinguished from carpal tunnel syndrome because in carpal tunnel syndrome, sensation over the thenar eminence is preserved (the sensory branch of the median nerve that innervates the thenar eminence does not pass through the carpal tunnel).

• There are negative Tinel's and Phalen's tests at the wrist in pronator syndrome and difficulty making the 'OK' sign.

• Treatment is rest/modification of activity, ice, analgesia, physiotherapy and occupational therapy.

Radial tunnel syndrome

• This is due to entrapment of the radial nerve.

• Pain is experienced distal to the lateral epicondyle of the humerus and radiates down the dorsum of the forearm.

• It is often misdiagnosed as lateral epicondylitis.

• A Tinel's test approximately 6 cm distal to the lateral epicondyle over the radial nerve can reproduce pain. There is also pain on resisted supination with the forearm extended.

• Treatment is rest/modification of activity, ice, analgesia, physiotherapy and occupational therapy.
