Barium tests

Barium tests are used to help see the outline of various parts of the gut (gastrointestinal tract). These include the gullet (oesophagus), stomach, upper gut (small intestines) and colon (large intestine).

Barium X-ray tests are done less commonly these days. Today we usually look into the gut with a flexible telescope (endoscopy or colonoscopy) . However, there is still a place for barium tests to help assess various problems of the gut.

Note: the information below is a general guide only. The arrangements, and the way tests are performed, may vary between different hospitals. Always follow the instructions given by your doctor or local hospital.

Continue reading below

Why is barium used during some X-ray tests?

The gut (gastrointestinal tract) does not show up very well on ordinary X-ray pictures. However, if you drink a white liquid that contains a chemical called barium sulfate, the outline of the upper parts of the gut (oesophagus, stomach and small intestines) shows up clearly on X-ray pictures. Similarly, if barium is placed in the colon this can also be seen clearly on X-ray. This is because X-rays do not pass through barium.

Types of barium test

Diagram naming the parts of the gut

The Gut - simple

Depending on what part of your gut is being looked at, you may have one or more of the tests listed below. In each test, the barium coats the lining of the gut being tested. Therefore, abnormalities in the lining or structure of the gut can be seen on the X-ray pictures.

In each of the following tests, several X-ray pictures are taken using low-dose X-rays. The total amount of radiation for each test is quite small and thought to be safe. The X-ray machine is usually linked to a TV monitor. Still pictures, or a video recording of X-ray pictures taken in quick succession, can be taken if necessary.

Continue reading below

Barium swallow

In this test you drink some barium liquid. The barium liquid is often fruit-flavoured so it is pleasant to drink. You stand in front of an X-ray machine whilst X-ray pictures are taken as you swallow. This test aims to look for problems in the gullet.

These include a narrowing (stricture), hiatus hernias, tumours, reflux from the stomach, disorders of swallowing, etc. You will usually be asked not to eat or drink for a few hours before this test. A barium swallow test takes about 10 minutes.

Barium swallow X-ray

Barium swallow

By Netha Hussain (Own work) via Wikimedia Commons

Barium meal

This is similar to a barium swallow. However, it aims to look for problems in the stomach and the first part of the gut (small intestine), known as the duodenum. These problems may include ulcers, small fleshy lumps (polyps), tumours, etc.

You drink some barium liquid but you then lie on a couch whilst X-ray pictures are taken over your tummy. It may take a little longer to do than a barium swallow.

So that the barium coats all around the lining of the stomach, the doctor doing the test (radiologist) may do one or more of the following:

  • Ask you to swallow some bicarbonate powder and citric acid before swallowing the barium. These 'fizz up' when they mix in the stomach and make some gas. (You may have the urge to burp.) The gas expands the stomach and duodenum and also pushes the barium to coat the lining of the stomach and duodenum. This makes the X-ray pictures clearer. It is the shape and contours of the lining of the stomach and duodenum which need to be seen most clearly on the pictures.

  • Ask you to turn over on to your stomach on the couch. Various X-ray pictures may be taken whilst you are in different positions.

  • You may be given an injection of a drug that makes the muscles in the stomach and gut relax.

Can I eat before a barium meal?

You will usually be asked not to eat anything for several hours before this test. (Food particles in the gut can make it difficult to interpret the X-rays). However, you may be allowed sips of water up to two hours before the test.

Barium meal stomach X-ray

Barium meal stomach

By Lucien Monfils (Own work) via Wikimedia Commons

Continue reading below

Barium follow through

This test is similar to a barium meal but aims to look for problems in the small intestine. Therefore, you drink the barium liquid but then need to wait 10-15 minutes before any X-rays are taken. This allows time for the barium to reach the small intestine.

You may then have an X-ray every 30 minutes or so until the barium is seen to have gone through all the small intestine and reached the large intestine (colon). This test will last longer than the previous ones. The overall time taken will depend on how quickly your gut moves things along.

Barium follow through showing small bowel

Barium follow through

By Glitzy queen00 at English Wikipedia, via Wikimedia Commons

Small intestine enema

This test is similar to a barium follow through. However, instead of drinking the barium liquid, a thin tube is passed down your gullet, through the stomach and into the first part of the small intestine.

Barium liquid is then poured down the tube. This test is not commonly done but can give some different information about the small intestine to the tests above.

Barium enema

This is a test to take X-ray pictures of the colon. Instead of drinking the barium it is placed in your colon (large intestine). You will be asked to lie on a couch and a small tube is put into your back passage (anus) and gently pushed up a few centimetres. Barium liquid is then passed through the tube into your colon (large intestine). So that the barium coats all of the lining of the colon, the doctor doing the test may be do some of the following:

  • Ask you to change position on the couch, for example on your side or back.

  • Give you an injection of a drug that makes the muscles in the walls of the colon relax.

  • Pass some air down the enema tube into the colon. This may feel a little uncomfortable, like trapped wind. But it helps makes the x-ray pictures much clearer.

When the barium liquid has spread throughout the colon, several x-ray pictures are taken so that all parts of the colon can be seen. The tube is then removed and you can go to the toilet. This test takes around 15-20 minutes.

What preparation do I need to do before a barium test?

This will depend on which of the tests listed above you need to have. Your local hospital will give you advice on what to do before the procedure.

After you have had a barium X-ray test

  • You should be able to go home as soon as the test is finished.

  • You can eat normally straight after any barium test.

  • The barium does not get absorbed into the body. Therefore, it is rare for a barium test to cause any other complications or side-effects.

Are there any side-effects of a barium x-ray?

Some people feel a little sickly for a few hours afterwards.

The barium may make you constipated. Therefore, to help prevent constipation:

  • Have lots to drink for a day or so to flush the barium out of your gut.

  • Eat plenty of fruit and vegetables for a day or so.

  • See your doctor if you haven't passed any poo after three or four days.

The barium will make your poo white or pale until it has all come out of your gut (after a day or so).

If you had an injection to relax the muscles in your stomach, it may cause some blurring of your vision for an hour or so. If this happens it is best not to drive.

Some other points about barium X-ray tests

Tell your doctor if you have insulin-dependent diabetes, so that you can arrange for the best time for you to stop eating and for the test to be done.

Pregnant women, if possible, should not have an X-ray test, as there is a small risk that X-rays may harm the unborn child. This is why women are asked before having an X-ray whether they are, or might be, pregnant.

Further reading and references

  • Nin CS, Marchiori E, Irion KL, et al; Barium swallow study in routine clinical practice: a prospective study in patients with chronic cough. J Bras Pneumol. 2013 Nov-Dec;39(6):686-91. doi: 10.1590/S1806-37132013000600007.
  • Negreanu L, Smarandache G, Mateescu RB; Role of capsule endoscopy Pillcam COLON 2 in patients with known or suspected Crohn's disease who refused colonoscopy or underwent incomplete colonoscopic exam: a case series. Tech Coloproctol. 2014 Mar;18(3):277-83. doi: 10.1007/s10151-013-1054-3. Epub 2013 Aug 21.
  • Li YZ, Wu PH; Conventional radiological strategy of common gastrointestinal neoplasms. World J Radiol. 2015 Jan 28;7(1):7-16. doi: 10.4329/wjr.v7.i1.7.
